DF50 Drum Filter for Large-Scale Aquaculture and RAS
The CrawTec DF50 drum filter is a high-capacity mechanical filtration unit designed for industrial aquaculture systems with increased water flow requirements. It is widely used in shrimp, fish, and crayfish farming to maintain stable water quality by continuously removing suspended solids and organic residues.
The filter operates on a gravity-fed principle and is equipped with a rotating drum fitted with a fine filtration screen. As solid particles accumulate on the drum surface, the automatic washing system activates, ensuring uninterrupted filtration and reducing the need for manual cleaning.
Technical Specifications
- Filtration capacity: up to 50 m³
- Drum size: 650 × 500 mm
- Filtration rating: 63 microns
- Overall dimensions: 800 × 750 × 800 mm
- Housing material: corrosion-resistant polypropylene
- Inlet connections: 3 × 110 mm
- Outlet connections: 3 × 110 mm
- Waste outlet: 1 × 110 mm
- Installation type: gravity-fed
- Automatic washing pump: included
Applications and Operational Benefits
The DF50 drum filter is suitable for shrimp, fish, and crayfish farms, as well as for industrial water treatment systems where reliable mechanical filtration is essential. Its gravity installation allows easy integration into existing RAS and flow-through systems without complex modifications.
- High filtration performance for large water volumes
- Automatic self-cleaning with minimal operator involvement
- Low energy consumption due to efficient drum rotation
- Durable construction for continuous industrial operation
| Product Location | Kiev, Kyiv City, Ukraine |
