75 m³ Drum Filter for Aquaculture and Fish Farming
The CrawTec 75 m³ drum filter is a high-capacity mechanical filtration solution designed for intensive aquaculture and closed-circuit water systems. It provides continuous removal of suspended solids and organic contaminants, ensuring stable water quality for fish, shrimp, and crayfish farming.
Water passes through a stainless steel filtration screen with a fineness of 63 microns, capturing even the smallest particles. As contaminants accumulate, an automatic control system activates the cleaning cycle: the drum rotates and the integrated flushing pump washes impurities into the drain, allowing uninterrupted operation without manual intervention.
Technical Features
- Maximum flow capacity up to 75 m³
- Drum filtration mesh: stainless steel, 63 microns
- Housing material: food-grade polypropylene, 10 mm thick
- Overall dimensions: 900 × 900 × 1000 mm
- Inlet connections: 4 × 110 mm
- Outlet connections: 4 × 110 mm
- Gear motor power: 120 W for smooth drum rotation
- Automatic flushing system with integrated pump
Applications and Operational Benefits
This drum filter is suitable for medium and large-scale aquaculture facilities, including closed-circuit water systems, industrial fish farms, and high-volume ornamental ponds. It is commonly used in the cultivation of sturgeon, carp, shrimp, and Australian crayfish, where consistent water clarity is critical.
- Fully automated operation with level sensors
- Minimal maintenance and low operating costs
- Stable filtration performance under continuous load
- Energy-efficient design for long-term use
Custom Manufacturing Options
The 75 m³ model is part of CrawTec’s standard product range. Filters with alternative capacities, dimensions, or connection layouts can be custom designed and manufactured to meet specific project requirements, from small farms to large industrial aquaculture complexes.
| Product Location | Kiev, Kyiv City, Ukraine |
