150 m³ Drum Filter for Closed Water and Aquaculture Systems
The 150 m³ drum filter is a high-capacity mechanical filtration solution designed for modern recirculating and closed water systems. It effectively removes fine suspended solids and organic contaminants, helping to maintain stable water quality and optimal conditions for fish, shrimp, and other aquatic species.
The filter housing is manufactured from 12 mm thick food-grade polypropylene, providing excellent resistance to moisture, chemicals, and mechanical stress. Inside the unit, a large rotating drum equipped with a stainless steel filtration screen ensures reliable and continuous removal of impurities without interrupting system operation.
Filtration Process and Design
Water enters the filter through multiple inlet connections and passes evenly through the drum screen with a filtration fineness of 63 microns. Solid particles are retained on the screen surface, while purified water exits through the outlet connections. When contamination reaches a preset level, integrated sensors activate the automatic flushing cycle.
During flushing, the drum rotates and a powerful pump directs water jets onto the screen, washing accumulated debris into the drain. This fully automated process eliminates the need for constant operator supervision and ensures uninterrupted filtration.
Technical Features
- Filtration capacity: up to 150 m³
- Drum size: 750 × 1200 mm
- Filtration rating: 63 microns, stainless steel mesh
- Housing material: food-grade polypropylene, 12 mm thickness
- Drive system: 250 W gearmotor for continuous operation
- Inlet connections: 4 × 110 mm and 2 × 160 mm
- Outlet connections: matching inlet configuration
- Automatic self-cleaning with integrated flushing pump
- Gravity-based installation for easy system integration
Applications and Customisation
This 150 m³ drum filter is suitable for large fish farms, aquaculture facilities, water treatment plants, and ornamental or technical ponds where high filtration capacity and reliability are required. The robust construction and automated operation make it ideal for continuous industrial use.
The model represents one of several available configurations. Custom drum filters with different dimensions, capacities, and connection layouts can be designed and manufactured to meet specific project requirements.
| Product Location | Kiev, Kyiv City, Ukraine |
